OSpectreComplex Class Reference

#include <spectre.h>

Inheritance diagram for OSpectreComplex:

Collaboration diagram for OSpectreComplex:

Public Member Functions
	OSpectreComplex ()
	OSpectreComplex (const TYComplex &defaultValue)
	OSpectreComplex (const OSpectreComplex &other)
	OSpectreComplex (const OSpectre &other)
	OSpectreComplex (const OSpectre &spectre1, const OSpectre &spectre2)
virtual	~OSpectreComplex ()
OSpectreComplex &	operator= (const OSpectreComplex &other)
	operators More...
OSpectreAbstract &	operator= (const OSpectreAbstract &other) override
	operator= More...
bool	operator== (const OSpectreComplex &other) const
bool	operator!= (const OSpectreComplex &other) const
OSpectreComplex	operator+ (const OSpectreComplex &spectre) const
OSpectreComplex	operator* (const OSpectreComplex &spectre) const
	Product of two complex spectrums (module/phase) More...
OSpectreComplex	operator* (const OSpectre &spectre) const
	Computes the operation between a complex spectrum times a spectrum. More...
OSpectreComplex	operator* (const double &coefficient) const
	Multiply a complex spectrum by a double coefficient. More...
OSpectreComplex	operator/ (const OSpectreComplex &spectre) const
	Divide a complex spectrum by another one. More...
double *	getTabValImag ()
	Get an array of the imaginary values of the spectrum. More...
const double *	getTabValImag () const
void	setValue (const double &freq, const double &reel, const double &imag=0.0)
void	setValue (const double &freq, const TYComplex &cplx)
double	getValueImag (double freq, bool *pValid=0)
void	setPhase (const OSpectre &spectre)
void	setPhase (const double &valeur=0.0)
OSpectre	getPhase () const
OSpectre	getModule () const
OSpectreComplex	toModulePhase () const
	Conversion to module/phase. More...
Public Member Functions inherited from OSpectre
	OSpectre ()
	Default constructor, the spectrum module is defined by the _defaultValue. More...
	OSpectre (double defaultValue)
	Constructor, the spectrum module is defined by the defaultValue given in parameter. More...
	OSpectre (const OSpectre &other)
	Copy constructor. More...
	OSpectre (const OSpectreAbstract &other)
	Copy constructor from OSpectreAbstract. More...
	OSpectre (const double *valeurs, unsigned nbVal, unsigned decalage)
	Constructor from an array (needed for the Harmonoise model) More...
virtual	~OSpectre ()
	Destructor. More...
OSpectre &	operator= (const OSpectre &other)
	operator= More...
virtual bool	operator== (const OSpectre &other) const
	operator== More...
virtual bool	operator!= (const OSpectre &other) const
	operator != More...
double *	getTabValReel () override
const double *	getTabValReel () const override
OSpectreAbstract *	getConcreteInstance () const override
	Return an instance of a concrete class of the same type as current. More...
void	setValue (const double &freq, const double &reel=0.0)
double	getValueReal (double freq)
bool	isTonalite () const
	Existence d'une tonalite marquee. More...
Public Member Functions inherited from OSpectreAbstract
	OSpectreAbstract ()
	Methods. More...
	OSpectreAbstract (TYSpectreForm form)
	OSpectreAbstract (bool isValid, TYSpectreType type, TYSpectreEtat etat, TYSpectreForm form)
virtual bool	operator== (const OSpectreAbstract &other) const
	operator== More...
virtual bool	operator!= (const OSpectreAbstract &other) const
	operator != More...
OSpectreAbstract &	operator+ (const double &valeur) const
	Add a constant value to all the spectrum. More...
OSpectreAbstract &	operator+ (const OSpectreAbstract &spectre) const
	Arithmetic sum of two spectrums in one-third Octave. More...
OSpectreAbstract &	operator- (const OSpectreAbstract &spectre) const
	Arithmetic subtraction of two spectrums in one-third Octave. More...
OSpectreAbstract &	operator* (const OSpectreAbstract &spectre) const
	Multiplication by a Spectre spectrum. More...
OSpectreAbstract &	operator* (const double &coefficient) const
	Multiplication by a double coefficient. More...
OSpectreAbstract &	sumdB (const OSpectreAbstract &spectre) const
	Energetic sum of two spectrums. More...
void	setDefaultValue (const double &valeur=TY_SPECTRE_DEFAULT_VALUE)
bool	isValid () const
	Check the spectrum validity. Invalidity is caused by: corrupted data, impossible calculation. More...
void	setValid (const bool &valid=true)
TYSpectreType	getType () const
	Get the spectrum type. More...
void	setType (TYSpectreType type)
	Set the spectrum type. More...
TYSpectreEtat	getEtat () const
	Get the spectrum state. More...
const TYSpectreEtat	getEtat ()
void	setEtat (TYSpectreEtat etat)
	Force the spectrum state (to use carefully ...) More...
TYSpectreForm	getForm () const
	Get the spectrum form. More...
void	setForm (TYSpectreForm form)
	Force the spectrum state (to use carefully ...) More...
unsigned int	getNbValues () const
	Number of values in the spectrum. More...
void	setDefaultValue (double module[], const unsigned int spectreNbElmt=TY_SPECTRE_DEFAULT_NB_ELMT, const double &valeur=TY_SPECTRE_DEFAULT_VALUE)
void	getRangeValueReal (double *valeurs, const short &nbVal, const short &decalage)
OSpectreAbstract &	sum (const OSpectreAbstract &spectre) const
	Arithmetic sum of two spectrums in one-third Octave. More...
OSpectreAbstract &	sum (const double &value) const
	Arithmetic sum of a spectrum and a double scalar. More...
OSpectreAbstract &	mult (const OSpectreAbstract &spectre) const
	Multiplication of two spectrums. More...
OSpectreAbstract &	mult (const double &coefficient) const
	Multiply this spectrum par a double scalar. More...
OSpectreAbstract &	div (const OSpectreAbstract &spectre) const
	Division of two spectrums. More...
OSpectreAbstract &	div (const double &coefficient) const
	Division of this spectrum by a double scalar. More...
OSpectreAbstract &	subst (const OSpectreAbstract &spectre) const
	Arithmetic subtraction of two spectrums in one-third Octave. More...
OSpectreAbstract &	subst (const double &valeur) const
	Subtract a constant value to this spectrum. More...
OSpectreAbstract &	invMult (const double &coefficient=1.0) const
	Division of a double constant by this spectrum. More...
OSpectreAbstract &	inv () const
	Division of one by this spectrum. More...
OSpectreAbstract &	power (const double &puissance) const
	Return a spectrum as this spectrum raised to a double power. More...
OSpectreAbstract &	log (const double &base=10.0) const
	Compute the log base n of this spectrum (n=10 by default). More...
OSpectreAbstract &	racine () const
	Compute the root square of this spectrum. More...
OSpectreAbstract &	exp (const double coef=1.0)
	Compute e^(coef * spectre) of this spectrum. More...
OSpectreAbstract &	sin () const
	Compute the sin of this spectrum. More...
OSpectreAbstract &	cos () const
	Compute the cos of this spectrum. More...
OSpectreAbstract &	abs () const
	Return the absolute value of this spectrum. More...
OSpectreAbstract &	sqrt () const
	Return the root square of a spectrum. More...
double	valMax ()
	Return the maximum value of a spectrum. More...
OSpectreAbstract &	seuillage (const double &min=-200.0, const double max=200.0)
	Limit the spectrum values (min and max) More...
double	sigma ()
	Sum the values of the spectrum. More...
const double	sigma () const
OSpectreAbstract &	toDB () const
	Converts to dB. More...
OSpectreAbstract &	toGPhy () const
	Converts to physical quantity. More...
double	valGlobDBLin () const
	Compute the global value dB[Lin] of a one-third Octave spectrum. More...
double	valGlobDBA () const
	Compute the global value dB[A] of a one-third Octave spectrum. More...
OSpectreAbstract &	toTOct () const
	Converts to one-third Octave. More...
OSpectreAbstract &	toOct () const
	Converts to Octave. More...
OSpectreAbstract &	round ()
virtual void	printme () const
	Print the spectrum. More...

Static Public Member Functions
static OSpectreComplex	getCplxSpectre (const double &valInit=1.0E-20)
	Build a OSpectreComplex complex spectrum. More...
Static Public Member Functions inherited from OSpectre
static OSpectre	getEmptyLinSpectre (const double &valInit=1.0E-20)
	Create a physical quantity spectrum. More...
static OSpectre	makeOctSpect ()
	Make a spectrum in Octave. More...
static int	getIndice (const double &freq)
	Return the index associated to a frequency. More...
static void	setFMin (const double &fMin)
	Define minimal frequency. More...
static void	setFMax (const double &fMax)
	Define maximal frequency. More...
static OTabFreq	getTabFreqExact ()
static OSpectre	getOSpectreFreqExact ()
	Return the spectrum of the exact frequencies. More...
static std::map< double, int >	setMapFreqIndice ()
	Construction du tableau frequence/indice. More...
static OSpectre	pondA ()
	Build a weighted spectrum A. More...
static OSpectre	pondB ()
	Build a weighted spectrum B. More...
static OSpectre	pondC ()
	Build a weighted spectrum C. More...
static OSpectre	getLambda (const double &c)
Static Public Member Functions inherited from OSpectreAbstract
static OSpectreAbstract &	makeOctSpect ()
	Make a spectrum in Octave. More...

Protected Attributes
double	_phase [TY_SPECTRE_DEFAULT_NB_ELMT]
	Array of the imaginary numbers (phase) More...
Protected Attributes inherited from OSpectre
double	_module [TY_SPECTRE_DEFAULT_NB_ELMT]
	Real values array for module. More...
Protected Attributes inherited from OSpectreAbstract
bool	_valid
	Spectrum validity. More...
TYSpectreType	_type
	Spectrum type. More...
TYSpectreEtat	_etat
	Spectrum state (physical quantity or dB). More...
TYSpectreForm	_form
	Representation of the spectrum: one-third Octave, Octave, constant delta f, unstructured. More...

Additional Inherited Members
Static Protected Attributes inherited from OSpectre
static const double	_freqNorm []
	Array of center frequencies (Hz) normalized in one-third Octave. More...
static double	_fMin = 16
	Minimal frequency. More...
static double	_fMax = 16000
	Maximal frequency. More...
static std::map< double, int >	_mapFreqIndice = setMapFreqIndice()
	Mapping between frequency and array index. More...
Static Protected Attributes inherited from OSpectreAbstract
static double	_defaultValue = TY_SPECTRE_DEFAULT_VALUE
	Default value for the spectrum. More...

Detailed Description

Define a module/phase spectrum

Definition at line 479 of file spectre.h.

Constructor & Destructor Documentation

OSpectreComplex() [1/5]

OSpectreComplex::OSpectreComplex

(

)

Definition at line 1144 of file spectre.cpp.

OSpectreComplex() [2/5]

OSpectreComplex::OSpectreComplex

(

const TYComplex &

defaultValue

)

Definition at line 1152 of file spectre.cpp.

OSpectreComplex() [3/5]

OSpectreComplex::OSpectreComplex

(

const OSpectreComplex &

other

)

Definition at line 1160 of file spectre.cpp.

OSpectreComplex() [4/5]

OSpectreComplex::OSpectreComplex

(

const OSpectre &

other

)

Constructor from a OSpectre (which is the module of the complex spectrum)

Definition at line 1165 of file spectre.cpp.

Here is the call graph for this function:

OSpectreComplex() [5/5]

OSpectreComplex::OSpectreComplex	(	const OSpectre &	spectre1,
		const OSpectre &	spectre2
	)

Constructor from 2 OSpectre : module and phase

Definition at line 1174 of file spectre.cpp.

~OSpectreComplex()

OSpectreComplex::~OSpectreComplex ( )

virtual

Definition at line 1183 of file spectre.cpp.

Member Function Documentation

getCplxSpectre()

OSpectreComplex OSpectreComplex::getCplxSpectre ( const double &  valInit = 1.0E-20 )

static

Build a OSpectreComplex complex spectrum.

Definition at line 1404 of file spectre.cpp.

Here is the call graph for this function:

getModule()

OSpectre OSpectreComplex::getModule

(

)

const

Get the module of this spectrum.

Definition at line 1375 of file spectre.cpp.

Here is the call graph for this function:

getPhase()

OSpectre OSpectreComplex::getPhase

(

)

const

Get the phase of this spectrum.

Returns

A OSpectre.

Definition at line 1365 of file spectre.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

getTabValImag() [1/2]

double* OSpectreComplex::getTabValImag ( )

inline

Get an array of the imaginary values of the spectrum.

Definition at line 513 of file spectre.h.

Here is the caller graph for this function:

getTabValImag() [2/2]

const double* OSpectreComplex::getTabValImag ( ) const

inline

Definition at line 517 of file spectre.h.

getValueImag()

double OSpectreComplex::getValueImag	(	double	freq,
		bool *	pValid = 0
	)

Get for a frequency the imaginary number from the Frequency/Complex array

Parameters

freq	Frequency.
pValid	False if the frequency is not valid for this spectrum.

Returns

Imaginary number

Definition at line 1343 of file spectre.cpp.

operator!=()

bool OSpectreComplex::operator!=

(

const OSpectreComplex &

other

)

const

Definition at line 1242 of file spectre.cpp.

Here is the call graph for this function:

operator*() [1/3]

OSpectreComplex OSpectreComplex::operator*

(

const double &

coefficient

)

const

Multiply a complex spectrum by a double coefficient.

Definition at line 1301 of file spectre.cpp.

operator*() [2/3]

OSpectreComplex OSpectreComplex::operator*

(

const OSpectre &

spectre

)

const

Computes the operation between a complex spectrum times a spectrum.

Definition at line 1285 of file spectre.cpp.

operator*() [3/3]

OSpectreComplex OSpectreComplex::operator*

(

const OSpectreComplex &

spectre

)

const

Product of two complex spectrums (module/phase)

Definition at line 1269 of file spectre.cpp.

operator+()

OSpectreComplex OSpectreComplex::operator+

(

const OSpectreComplex &

spectre

)

const

Definition at line 1247 of file spectre.cpp.

operator/()

OSpectreComplex OSpectreComplex::operator/

(

const OSpectreComplex &

spectre

)

const

Divide a complex spectrum by another one.

Definition at line 1315 of file spectre.cpp.

operator=() [1/2]

OSpectreAbstract & OSpectreComplex::operator= ( const OSpectreAbstract &  other )

overridevirtual

operator=

Reimplemented from OSpectre.

Definition at line 1199 of file spectre.cpp.

Here is the call graph for this function:

operator=() [2/2]

OSpectreComplex & OSpectreComplex::operator=

(

const OSpectreComplex &

other

)

operators

Definition at line 1185 of file spectre.cpp.

Here is the call graph for this function:

operator==()

bool OSpectreComplex::operator==

(

const OSpectreComplex &

other

)

const

Definition at line 1224 of file spectre.cpp.

Here is the caller graph for this function:

setPhase() [1/2]

void OSpectreComplex::setPhase

(

const double &

valeur = 0.0

)

Set the phase to this spectrum.

Parameters

valeur

A double.

Definition at line 1357 of file spectre.cpp.

setPhase() [2/2]

void OSpectreComplex::setPhase

(

const OSpectre &

spectre

)

Set the phase to a spectrum.

Parameters

spectre

A OSpectre.

Definition at line 1349 of file spectre.cpp.

setValue() [1/2]

void OSpectreComplex::setValue	(	const double &	freq,
		const double &	reel,
		const double &	imag = 0.0
	)

Set a complex value to the array Frequency/Complex.

Parameters

freq	Frequency.
reel	Real number.
imag	Imaginary number.

Definition at line 1331 of file spectre.cpp.

Here is the caller graph for this function:

setValue() [2/2]

void OSpectreComplex::setValue	(	const double &	freq,
		const TYComplex &	cplx
	)

Set a complex value to the array Frequency/Complex.

Parameters

freq	Frequency.
cplx	A TYComplex complex number

Definition at line 1338 of file spectre.cpp.

Here is the call graph for this function:

toModulePhase()

OSpectreComplex OSpectreComplex::toModulePhase

(

)

const

Conversion to module/phase.

Definition at line 1385 of file spectre.cpp.

Here is the caller graph for this function:

Member Data Documentation

_phase

double OSpectreComplex::_phase[TY_SPECTRE_DEFAULT_NB_ELMT]

protected

Array of the imaginary numbers (phase)

Definition at line 577 of file spectre.h.

---

The documentation for this class was generated from the following files:

• /home/docs/checkouts/readthedocs.org/user_builds/code-tympan-fbessou/checkouts/latest/Tympan/models/common/spectre.h
• /home/docs/checkouts/readthedocs.org/user_builds/code-tympan-fbessou/checkouts/latest/Tympan/models/common/spectre.cpp
